Full carbon frame featuring leading edge carbon fiber materials and Pivot’s proprietary hollow core internal molding technology.
New 12 x 148mm Boost rear spacing for maximum stiffness and control.
Designed to work with forks from 120-130mm in travel.
Fox Float DPS shock, performance tuned for the Mach 429 Trail.
29-inch wheels for the fastest laps and superior rollover in technical terrain.
27.5”+ capable!
Easy to use mix of external and internal cable routing with Pivot’s internal cable port system.
Internal dropper post compatible.
Cold forged alloy linkages with Enduro Max Cartridge Bearings.
Pivot’s innovative new mid-travel linkage design.
116mm of renowned dw-link® suspension tuned for trail handling. (truly feels like a 100mm bike when climbing and a 130mm bike when descending)
Post mount disc brake mounts for precision and weight savings.
PF92 bottom bracket for light weight, durability and ease of maintenance. Co-designed by Pivot Cycles and Shimano, now the industry-leading standard for high-end mountain bikes.
New Pivot removable front derailleur mount for a clean frame design with 1X and perfect front shifting with Shimano’s side-swing 2X system.
Highly durable rubberized leather downtube and swingarm protection
